Aramid Paper is of high temperature insulation paper made of pure aramid fiber and exhibits numerous excellent properties
color：
white
Free sample：
A4
Thermal Class：
C 220℃
Available width：
customized
Thickness：
0.06-0.38mm
Quantity
Quantity
Description
Application
Related Product
Aramid Paper
Description:
Aramid Paper is of high temperature insulation paper made of pure aramid fiber and exhibits numerous excellent properties such as high strength, low deformation, heat resistance, flame resistance, resistance to chemicals, good dielectric property and etc. It can be widely used in dry-type transformers, special transformers, microwave oven transformers, HID ballasts and other transformers as turn to turn insulation, interlayer insulation and insulation end. It can also be used in metallurgy, lifting, hauling, mining, explosion-proof, marine, wind power and other special motors and generators as slot insulation, liner insulation and turn insulation. It has temperature insulation rating of 220'C and can provide higher level of electrical equipment security
Features Good thermal stability, flame resistance, electrical insulation, high dielectric strength, good mechanical properties, Chemical stability, radiation resistance.
